Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor

    Buy cheap Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor from wholesalers

    Buy cheap Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor from wholesalers
    • Buy cheap Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor from wholesalers

    Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor

    Ask Lasest Price
    Brand Name : Zetron
    Model Number : ZN311A
    Certification : CE/Atex
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : in stock
    • Product Details
    • Company Profile

    Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor

    Zetron ZN311A Online Nitrogen Purity Analyzer


    OVERVIEW


    ZN311A Nitrogen Purity Analyzer is a new-type intelligent industrial online analyzer researched and developed by combining imported high-performance electrochemical sensor, which is used to detect oxygen and display nitrogen purity, with new microcomputer technology.

    Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor

    FEATURES
    • Imported fuel cell sensor adopted, featuring long service life, high accuracy, and quick response;
    • Small volume and lightweight, making the instrument especially suitable for places where the installation space is relatively small;
    • Automatic range shifting; upper/lower limit alarm can be set at will within the whole range;
    • Alarm point can be set at will within the whole range;
    • RS232 or RS485 communication interface available for two-way communication with computer.
    SPECIFICATION

    Measurement range

    75~99.99% N2 optional

    Accuracy

    ≤ ±2% F.S

    Stability

    Zero drift ≤ ±1% F.S/7d;
    Span drift ≤ ±1% F.S/7d;

    Repeatability

    ≤ ±0.5%

    Sample gas flow

    300±10 ml/min

    Response time

    90 ≤ 15 sec.

    Sample gas pressure

    0.05 MPa ≤ Inlet Pressure ≤ 0.1 MPa

    Resolution

    0.01%

    Contact capacity

    120 VAC, 1A 24 VDC, 1A

    Output signal

    4~20 mA

    Operating environment

    Temperature: -5℃~+45℃;
    Humidity: ≤ 90% RH;

    Operating power supply

    220 VAC±10%, 50 Hz±5%

    Overall dimensions

    160 mm (W) × 80 mm (H) × 250 mm (D)

    Mounting dimensions

    152 mm (W) × 76 mm (H)

    Weight

    About 1 kg


    APPLICATION


    Detecting oxygen content in nitrogen production by air separation, chemical process, magnetic materials, and protective gases for high-temperature sintering furnaces and displaying it as nitrogen purity.


    Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor


    FAQ

    Q: What are your terms of payment?
    A: We accept trade assurance, western union, visa master card, and tt.
    Trade assurance can protect you, when you confirm the product then the money into my account.

    Q: When do you reply to messages?
    A: We will reply you for your inquiry in 24 hours.

    Q: What is the warranty for your product?
    A: Warranty: 12 months, Lifetime maintenance

    Q: When do you send the products? And how do you send it?
    A: For the small order, we will send out the goods within 5 days, If have stock ,we will send it immediately.
    We send them by ups, FedEx, TNT, or DHL. For big order, normal is 20 days will finish.

    Q: Do you accept OEM or revised logo, color, model, size?
    A: Yes, we accept OEM for the qualified buyer. We can make the products according to customer personal requirement.

    Q: How about the quality of the management?
    A: We have a complete quality control system, all of our products will be fully pre-inspection by QC departments before shipping to you. We have the certification of ISO, CE we could send the certification test of our company to you.

    Q: How about your after-sale service?
    A: After sending, we will track the products for you, until you get the products.
    When you got the goods, test them, and give me a feedback.
    If you have any questions about the problem, contact us, we will offer the solve way for you.

    Quality Online Infrared Syngas Analyzer 300ml/Min Nitrogen Purity Analyzer With Electrochemical Sensor for sale
