    Three Wavelength Triple Infrared Flame Detector IP66 Explosion Proof Dustproof

    Ask Lasest Price
    Brand Name : zetron
    Model Number : MIC-200-IR3
    Certification : CE, Atex, RohS, ISO
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : in stock
    • Product Details
    • Company Profile

    Three Wavelength Triple Infrared Flame Detector IP66 Explosion Proof Dustproof

    Zetron MIC-200-IR3 Three wavelength Infrared Flame Gas Detector

    OVERVIEW

    The MIC200 Three-band Infrared Flame Detector is Sight Gas detection System is a proven open path gas detection solution which aids in high speed detection of flammable gases such as Methane, Ethane, Propane, Butane, Pentane, Ethylene, Propylene, Butadiene in Short range (5 to 40m) distances comes with approved certification for ATEX.

    It's a reliable and high-performance flame detector. It uses advanced flame analysis and identification technology to quickly respond to infrared radiation in a fire and has the highest false alarm immunity .
    The MIC-200-IR3 detector contains three narrow-band infrared sensors (4-6 microns) and optical filters, which have high sensitivity to carbon dioxide emission spectra (4.4 microns), which can effectively eliminate interference and achieve detection for a much longer distance.


    The special fire signal processing method and multi-sensor detection technology greatly improve the sensitivity and response time of the detector. The detector is suitable for liquid and gas fires, open flames with smoke and places where deflagration occurs.

    Three Wavelength Triple Infrared Flame Detector IP66 Explosion Proof Dustproof

    SPECIFICATION

    Response spectral range
    4-5um
    Response time
    5--10s The response time of different media is different
    Viewing angle range
    90 °
    Detection distance
    30--50 meter (depends on the burning material)
    Ambient temperature
    -10 ~ 55 ℃
    Environmental humidity
    ≤95% RH
    Pressure range
    86 ~ 106Kpa
    Working voltageDC24V
    Working currentcurrent≤25mA, alarm current≤35mA
    Executive standardGB15631-2008, GB3836- 2000 series
    Explosion-proof grade
    EXdⅡCT6
    Protection grade
    IP66
    Signal output4~20mA three-wire system output
    Installation methodwall or ceiling
    Cable outlet thread20mmX1.5mm free conversion G1 / 2 optional
    Dimensions
    19*16*11 cm
    Shell material
    aluminum alloy, surface anticorrosive paint sprayed
    Weight1.7 Kg
    Advantagesdustproof, explosion-proof, corrosion-proof

    FEATURES & BENEFITS

    • Developed by the principle of three- wavelength infrared detection, it has high immunity to false alarms;
    • High-speed response to flame;
    • Built-in high-performance microprocessor;
    • Excellent anti-radio frequency and electromagnetic interference performance;
    • Reliable system fault self-diagnosis function;
    • Two output modes of three-wire current loop and relay are optional;
    • Patented signal processing algorithm to minimize the possibility of false alarms;
    • Multi-level sensitivity settings to meet the different needs of more occasions;
    • Easy to install, the detection angle can be adjusted by 360° ;
    • ExdII CT6 explosion-proof grade, suitable for zone 1 and zone 2 hazardous locations.
