UV Flue Gas Analyzer 200℃ Stainless Steel Heating Boiler Emission Gases Dual Beam Micro Flow Technology

    Buy cheap UV Flue Gas Analyzer 200℃ Stainless Steel Heating Boiler Emission Gases Dual Beam Micro Flow Technology from wholesalers

    Buy cheap UV Flue Gas Analyzer 200℃ Stainless Steel Heating Boiler Emission Gases Dual Beam Micro Flow Technology from wholesalers
    • Buy cheap UV Flue Gas Analyzer 200℃ Stainless Steel Heating Boiler Emission Gases Dual Beam Micro Flow Technology from wholesalers

    UV Flue Gas Analyzer 200℃ Stainless Steel Heating Boiler Emission Gases Dual Beam Micro Flow Technology

    Ask Lasest Price
    Brand Name : Zetron
    Model Number : Gasboard 3800UV
    Certification : CE, ISO13485, ISO9001
    Payment Terms : T/T, D/A, L/C, D/P, Western Union, MoneyGram
    Supply Ability : 1000 set/month
    Delivery Time : 3-7 days
    • Product Details
    • Company Profile

    UV Flue Gas Analyzer 200℃ Stainless Steel Heating Boiler Emission Gases Dual Beam Micro Flow Technology

    Portable UV Flue Gas Analyzer

    OVERVIEW

     It is new portable type that adopts the UV DOAS, NDIR, and electrochemical technology to measure the concentration of SO2, NO, CO, CO2, HC, and O2 from stack or boiler emission gases, with optional gas temperature, velocity, combustion efficiency, air coefficient, etc.


    FEATURES

    Gas conditioning device features

      1) Stainless steel heating type sampling probe, heating temperature up to 200℃.
      2) The probe is equipped with SIC filter element for quick replacement.
      3) Sampling probes are available in different lengths (1 or 2 meters) to suit various industrial applications.
      4) Heating tube has a self-controlled temperature function to keep high temperature of 180℃, it can prevent SO2 gas condensation to lose value.
      5) Originally imported diaphragm pump, flow rate ≤60L/h.
      6) Gas-water separator to separate liquid water in the sample gas.
      7) Original Peltier cooler removes gaseous water from sample gas.
      8) Equipped with corrosion-resistant and pressure-resistant heat exchanger and independent digital PID controller.
      9) After treating, sample gas dew point:≤4℃, dust accuracy: 0.1μm.
    SPECIFICATION

    General Parameter
    MeasurementSO2, NO, CO, CO2, O2
    TechnologySO2, NO, CO: Dual-beam micro-flow NDIRtechnology
    CO2: NDIR technology
    O2: long lifetime ECD technology
    RangeS02, NO: (0-500-2000)mg/m
    CO (0-5000)mg/m
    CO2,O2: (0-25) %
    (Note: Measurement range can be customized)
    ResolutionSO2, NO, CO: 1mg/m3
    CO2,O2 : 0. 01%
    PrecisionSO2, NO, CO: 1mg/m3
    Repeatability< 2%
    Stability<2%S/24h
    Response time (T90)30s
    Warm up time5min
    Communication interfaceUSB, or Dot matrix printer
    Power supplyAC 220 v + 10%, 50 Hz
    Inlet gas flow(0.7-1.2)L/min
    DisplayLCD display
    Working Environment
    Work temperature0-50 ℃
    Relative humidit5-85%
    Ambient pressure86-108kPa
    Dimensions
    Size275mm*470mm*175mm
    Weight7.2 kg

    APPLICATION

    Boiler, furnace exhaust emission gas and combustion efficiency monitoring, cement production line process and security monitoring, CEMS integration.
