    MIC200-FD706EX Uv Flame Detector Outdoor Point Type With Ultraviolet Optical Sensor

    MIC200-FD706EX UV Flame Detector

    OVERVIEW
    The Explosion-Proof Point-Type UV flame detector AW-FD706EX has high sensitivity to monitor early flame of ultraviolet radiation, can provide rapid alarm response to most flames, and has reliable self-
    diagnosis and excellent explosion-proof performance. It is well applied in dangerous places where flames are easy to occur quickly.
    SPECIFICATION

    Model
    MIC200-FD706EX
    Spectrum Range
    UV 185-260nm
    Detection angle
    120°
    Sensitivity level
    Grade I
    Main Voltage
    24VDC(18~30VDC)
    Ex-Atex Protection Level
    Exd II C T6 Gb/tD A21 IP66 T80°C
    Protection class
    IP66 / IP67
    Operation method
    Infrared remote control
    Temperature range
    -40℃~70℃
    Environmental Storage temperature range
    (-40~-85°F)
    Humidity
    0 ~ 96%RH (non-condensing) can withstand
    100% condensing humidity for a short time
    Materials and colors
    Cast Aluminum,The coating is an insulating layer,corrosion-resistant, Red
    Electrical Interface
    1×3/4NPT,M25*1.5,G3/4, optional
    Size
    120mm* 95mm* 85mm
    Weight about
    0.7kg

    APPLICATION

    The detector is widely used in petroleum, chemical industry, environmental protection, metallurgy, refining, biochemical medicine, agriculture, fire control, archaeology, and other industries and places that need safety detection of toxic and harmful, explosion prevention. The detector can effectively predict the concentration of dangerous gas alarms, to ensure that the safety of staff life is not threatened, and production equipment is not lost.
