OPC-P50 Portable Oil Particle Counter

1. ​ Adopting the principle of light blocking (shading) method and using high-precision laser sensor, it has small size, high precision and stable performance.

1. Suitable for laboratory or on-site testing, it can also be equipped with a pressure reducing device for online high-pressure measurement and real-time monitoring of particle contamination in the oil system
2. Can be connected to an external pressure chamber to form positive/negative pressure, enabling detection and sample degassing of high viscosity samples
3. Built-in data analysis system, which can display the real data of particle size in each channel and automatically determine the sample grade
4. The pipeline is made of 316L and PTFE materials to meet the detection of various organic solvents and oils.
5. It has volume flushing and time flushing modes, which is convenient for users to use and maintain the equipment
6. Built-in ISO4406, NAS1638, SAE4059 (integral and differential), GJB420A, GJB420B, Г OCT17216 , GB/T14039 and other particle pollution level standards
7. Built-in calibration function, can be calibrated according to GB / T21540 , ISO4402, GB / T 18854 and other standards
8. Built-in data analysis system, which can automatically determine the sample grade according to the standard, and has the function of automatic data processing and printing
9. Built-in water sensor and temperature sensor
10. Chinese and English bilingual, one-touch switching, with printing and storage functions, 1 0.2 -inch large screen, easy and fast operation
11. Large storage capacity, can be stored in the instrument or external storage device
12. Embedded design , high-strength shell, easy to carry, suitable for all kinds of engineering machinery

OPC-P50 can be widely used in aviation, aerospace, electric power, petroleum, chemical industry, transportation, port, metallurgy, machinery, automobile manufacturing and other fields.

PRODUCT PARAMETERS

​

​​​ Light source semiconductor laser Offline detection speed 5-60mL/min Offline sample viscosity ≤100cSt (optional pressure chamber for high viscosity) Online detection pressure 0.1 -0.6Mpa (optional pressure reducing device with maximum pressure up to 42Mpa) Particle size range 1-500μm Interface USB interface, power interface Data storage Provides 1,000 sets of data storage space and supports USB storage Sensitivity 0.8μm or 4μm (c) Limit coincidence error 40,000 particles/ml Counting volume 1-999 ml Counting accuracy error less than ±10% Protection level IP 67 Test time interval 1 second - 24 hours Detection sample temperature 0-80ºC Water activity reference value 0-1aw (±0.05aw) Water content 0-360ppm (±10%) Working temperature -20-60ºC Charging DC12.6V AC100~240V Weight 5.5kg Screen size 10.2 inches Battery capacity 8000mAh Volume 365*295*170mm ​ ​​

​
